Electrical Specifications
	Voltages Available	110 Volts 60 Hertz 1 Phase 230 Volts 50 Hertz 1 Phase 230 volts 60 Hertz 1 Phase
	Amperage	15 Amp Dedicated Line
		3 Running Amps ( 1.5 Amps @ 230V )
	NEMA Configuration	NEMA 5-15
	Certification(s)	ETL Listed
Control Specifications
	Temperature Control	Digital Display
	Min / Max Temperature	Display and Reset
	Temperature Alarm	Audible High / Low Alarm
	Additional Alarm Types	Power Failure, Low Battery
	Data Logging	Adjustable Intervals
	Data Display	Interactive Graph
	Data Download	Via USB. CSV Format
	Backup Battery	Only Powers Alarm
	Alarm Relay	Dry Contacts
General Specifications
	Defrost	Manual
	Air Circulation	Gravity Flow
	Compressor(s)	Variable Speed Compressor
	Refrigeration	Natural R2
	Insulation	Polyurethane CFC Free
	Opening	1 Front Door
	Opening Type	Hinged
	Door Material	Insulated Steel
	Lockable Door	Keyed Lock
	Access Porthole	Two
	Storage	Base Shelf
	Box Capacity	23 Two Inch Boxes ( Not Included )
	Exterior	Steel
	Interior	Stainless Steel
	Leveling Legs	2 Leveling, 2 Rollers
	Warranty	3 Years Parts and Labor
